Removing Lower Targa Bar Seal
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2019 Porsche 911, 2018 Porsche 911, 2017 Porsche 911, 2016 Porsche 911, and 2015 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
Information
- The number of fastening screws, fixing clips, plug connections, holders and trim panels can vary depending on equipment.
- The illustrations for removing and installing the drive mechanism are shown only on one equipment variant and may differ from the actual equipment variant.
- Some steps must be carried out automatically.
- Some of the repair illustrations show only one side of the vehicle.
- Loosen inner seal -1- from the trim panel and remove it.
- Loosen foam inserts -2, 3- from the trim panel and remove them.
- Loosen outer seal -4- from the trim panel and remove it.
- Cut off rubber pins -5- and loosen and remove seals from the trim panel.
