Installing Heating Element For Front Seat

WARNING: This page is about a different car, the 2010 Porsche Cayenne, 2009 Porsche Cayenne, and 2008 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.

Information

Install the heating elements starting from the right or left side bolster.

Align heating element to contour of padding.
Remove protective film and stick heating element -a- - starting from the front edge -Arrow A- - onto the padding -Arrow B- .

Fig 1: Installing Heating Elements For Side Bolsters And Lower Leg Support
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Remove protective film and stick heating element -b- - starting from the front edge -Arrow C- - onto the padding -Arrow D- .

Fig 2: Installing Heating Elements For Side Bolsters And Lower Leg Support
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Stick heating element on front edge of seat, starting from the top -Arrow E- .

Fig 3: Installing Heating Elements For Side Bolsters And Lower Leg Support
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Remove protective film, position heating element -c- at the height of the electrical lead -d- on the padding -Arrow F- and affix towards both sides -Arrows G- .

Fig 4: Installing Heating Elements For Side Bolsters And Lower Leg Support
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
