Replacing The Steering-Angle Sensor

WARNING: This page is about a different car, the 2010 Porsche Cayenne, 2009 Porsche Cayenne, and 2008 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Direction Indicator, Cruise Control Switch, Switch For Wiper/Washer System And Electronic Unit
G09419473Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  1. Direction indicator switch
  2. Cruise control switch
  3. Contact unit for airbag (spiral spring)
  4. Switch for wiper/washer system
  5. Electronic unit
  1. In order to replace the steering-angle sensor, the contact unit for airbag -C-  and the electronic unit -E-  must be replaced → 945019 REMOVING AND INSTALLING STEERING COLUMN SWITCH (REMOVING AND INSTALLING STEERING COLUMN SWITCH INCLUDES DISASSEMBLY AND ASSEMBLY) .
  2. Once installed, the steering-angle sensor must be calibrated for the PSM system using the Porsche System Tester → WM 456005 INITIALIZING AND CALIBRATING STEERING-ANGLE SENSOR (ALL MODELS)  .
