Preliminary Work

WARNING: This page is about a different car, the 2010 Porsche Cayenne, 2009 Porsche Cayenne, and 2008 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove lower trim panel in footwell (with diagnostic socket and footwell lighting) and the trim panel support on the bulkhead (only inserted) → Removing cover under dashboard .
  2. Remove lower dashboard trim panel → Removing trim panel under dashboard .
  3. Remove side cover of dashboard (fuse box) and the lower A-pillar trim panel → Removing front side section trim . To remove the A-pillar trim panel, only partial removal of the >> trim panel for front side section << is required!
    Fig 1: Identifying Pedal For Foot-Operated Parking Brake
    G09419642Courtesy of PORSCHE CARS NORTH AMERICA, INC.
