Component Overview

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
  1. Front loudspeakers (dashboard) at the left and right
  2. Front center loudspeaker (dashboard)
    3. Fig 1: Identifying Loudspeakers Installation Position
    G09941740Courtesy of PORSCHE CARS NORTH AMERICA, INC.
