Preparing Roof For Installation

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.

Grind both sides of connecting flanges of roof in the marked areas until bare.

Fig 1: Preparing Roof
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Preparing bonding areas (structural adhesive).

Fig 2: Preparing Roof Bonding Areas (Structural Adhesive)
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Preparing bonding areas (support adhesive).

Fig 3: Preparing Roof Bonding Areas (Support Adhesive)
Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Information

Do not apply zinc powder paint to the bonding areas.
Coat all spot-weld flange areas with zinc powder paint.
