Installing Right Cross Panel

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
  1. Push rubber seal -1-  onto the bodyshell flange and centre cross panel -A-  . Lightly coat the rubber seal with sliding compound, e.g. glycerine (to make it easier to refit the cross panel).
    Fig 1: Pushing Rubber Seal Onto Bodyshell Flange And Centre Cross Panel
    G09946585Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  2. Further installation of the left cross panel is performed in reverse order to removal.
