Preparing Front Side Member For Installation

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
  1. Grind both sides of the connecting flanges on the inner side member in the marked areas until bare.
    Fig 1: Identifying Inner Front Side Member For Installation
    G09938318Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  2. Grind both sides of the connecting flanges on the outer side member in the marked areas until bare.
    Fig 2: Identifying Outer Front Side Member For Installation
    G09938319Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  3. Coat all spot-weld flange areas with zinc powder paint.
