Preparing Connection Areas Of The Body For Installing Wing Mounting Point

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
  1. Clean welding and sealing areas.
    Fig 1: Identifying Body Welding And Sealing Areas
    G09938261Courtesy of PORSCHE CARS NORTH AMERICA, INC.
    1. 1.1. Clean the body connecting flanges of underbody protection, adhesive residue and paint in the marked areas.
    2. 1.2. Grind the connecting flanges until bare.
  2. Coat spot-weld flange areas with zinc powder paint.
