Replacing DME Control Unit: Notes

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.

Unscrew four fastening screws -1- on the bracket.

Fig 1: Replacing DME Control Unit (Shown As Example)
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Screw in four fastening screws -1- on the bracket. → Tightening Torque: 9 Nm (6.5 ft. lb.)
