Removing Bar Ignition Modules

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.

Pull out bar ignition modules. For securely seated bar ignition modules, use the special tool Puller T10095 A -A- to do this.

Fig 1: Removing Bar Ignition Modules
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
