WM 193817 Draining And Filling Coolant (Includes Bleeding) (Cayenne Diesel): Information

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.

Components of the radiator vacuum filling device

Pay attention to the special features in the corresponding article for vehicles with auxiliary heater.

Fig 1: Vacuum Filling Device Components Filling Device 9696

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

-1- - Adapter K 22 (installed in place of the cap on the coolant reservoir.)
-2- - Hose extension FZ 100 (installed between K22 and KVB 01.)
-3- - KVB 01 (vacuum pressure gauge with two shut-off valves)
-V1- - Shut-off valve V1 (shutoff valve for the filler hose.)
-V2- - Shut-off valve V2 (shutoff valve for the filler hose.)
-4- - Venturi nozzle (a vacuum is produced in this component by means of compressed air. A pressure of between 6 and 10 bar must be present.)
-5- - Filler hose (the cooling system is refilled via this hose.)
-6- - Return lines (the compressed air and extracted coolant are drawn off via this hose.)
