Technical Values: Differential

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2018 Porsche Cayenne, 2017 Porsche Cayenne, 2016 Porsche Cayenne, 2015 Porsche Cayenne, and 2014 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.

Location	Description	Type	Basic value	Tolerance 1	Tolerance 2
No. 1: Threaded connection securing differential to suspension subframe	M12 x 1.5 x 90 thread (always replace screws and lock nuts after removal)	Tightening torque	90 Nm (67 ftlb.)	+90°

Fig 1: Identifying Front Axle Differential

Courtesy of PORSCHE CARS NORTH AMERICA, INC.
