Installing Switch For Height And Fore-And-Aft Adjustment
WARNING: This page is about a different car, the 2014 Porsche Cayenne, 2013 Porsche Cayenne, 2012 Porsche Cayenne, and 2011 Porsche Cayenne. However, it is still accessible from the selected car via links, so may be relevant.
- Plug in electric plug connection -1-
.
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Plugging in connector
- Insert switch -2-
at the bottom first.
- Press the switch -2-
into the trim panel until the clip -1-
engages securely.
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Pressing in switch
