Removing Upper Part Of Valve

  1. Remove upper part of valve.
    1. 1.1. Unclip upper part of valve -1-  in an upwards direction.
      Fig 1: Removing Upper Part Of Valve
      G10024445Courtesy of PORSCHE CARS NORTH AMERICA, INC.
