Installing Spooling Device And Deflection Rollers On The Glass

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position spooling device -A3-  diagonally in the center of the glass.
  2. Press spooling device -A3-  with the fastening intakes firmly against the glass.
  3. Fix fastening intake onto the glass by moving the actuating lever.
    4. Fig 1: Identifying Spooling Device And Deflection Rollers On Glass
    G09826485Courtesy of PORSCHE CARS NORTH AMERICA, INC.
