Removing Frame For Side Airbag

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
  1. Unscrew fastening screws -1-  and unclip frame for side airbag -2-  from the backrest frame -3-  .
    Fig 1: Identifying Frame For Side Airbag And Nuts
    G09829593Courtesy of PORSCHE CARS NORTH AMERICA, INC.
