Installing Cup Holder

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
  1. Push cup holder -1-  into the shaft of the glove compartment.
  2. Tighten fastening screws M5 x 30 -2-  . Tightening torque → final tightening: 7.0 ftlb.
    3. Fig 1: Installing Cup Holder
    G09827209Courtesy of PORSCHE CARS NORTH AMERICA, INC.
