Removing Carbon Canister - RoW Version

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
  1. Unscrew collar nut M6 -1-  . Carefully pull carbon canister out of body mounting points in direction of travel.
    Fig 1: Identifying Carbon Canister For RoW
    G09828199Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  2. Release and remove plug-in couplings on the underside of the canister -2-  . Unclip lines from the mountings on the canister -3-  .
