Installing Desiccator (Fluid Tank)

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.

In any case, replace O-rings for the refrigerant lines and wet the new rings with refrigerant oil.

Only install a new desiccator.

  1. Position the fluid tank, connect the refrigerant lines and secure with the fastening screws -2-  . → M6: 4.5 ftlb.
  2. Connect the air-conditioning line -1-  and tighten with fastening nut.
  3. Tighten the hose clamp -3-  .
    4. Fig 1: Installing Desiccator
    G09830368Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  4. Determine the quantity of refrigerant oil. → Technical data for the air-conditioning system  , volume removed by suction + 30 cm3 .
