Installing Bottom Belt Strap Guide

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.

Position bottom belt strap guide -2- on the seat shell -3- and secure with the fastening screws -1- . → Tightening torque: 3 Nm (2 ftlb.)+/-0.5 Nm (+/-0.5 ftlb.)

Fig 1: Installing Bottom Belt Strap Guide
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
