94 - Lights, Lamps, Switches - Exterior
| Location | Description | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Fastening nuts securing headlight mounting to body | Tightening torque | 8 Nm (6 ftlb.) | |||
| Gap dimension -x- brake light switch | Gap between sensor and counter plate | Adjustment value | 1.5 mm | +/-0.5 mm | |
|
Adjusting brake light switch |
|||||
| Clamping screw for steering-column switch | Tightening torque | 6 Nm (4.5 ftlb.) | |||
| Fastening screw for tail light | Tightening torque | 5.8 Nm (4.5 ftlb.) | +10 % | -15 % | |
| Fastening screw for tail light | Tightening torque | 5.8 Nm (4.5 ftlb.) | |||
| Reflector cover fastening screw | Tightening torque | 4 Nm | +0.5 Nm | ||
| Threaded joint for angle sensor on holder | Tightening torque | 3.4 Nm (2.5 ftlb.) | |||
| Threaded joint for connecting link (angle sensor) on wishbone | Tightening torque | 4.5 Nm (3.5 ftlb.) | |||
| Additional brake light to lower part of rear spoiler | M5 collar nut, self-locking - replace | Tightening torque | 3 Nm (2 ftlb.) | ||
| Auxiliary headlight to front apron | Internal Torx screw, 6 x 18 | Tightening torque | 2.5 Nm (1.5 ftlb.) | ||
