Installing Wing Joining Plate

  1. Apply adhesive.
    Fig 1: Identifying Wing Joining Plate Adhesive Applying Area
    G10005280Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  2. Fit luggage compartment bracket.
  3. Rivet in luggage compartment bracket. → BLIND RIVET 000.043.207.59
