Removing The Tweeter (Premium), Left And Right

NOTE: Incorrect handling of components
  • Risk of irreparable damage to electric and electronic components
  • Reduced functionality

→ Switch off the ignition, remove the ignition key and switch off the audio system before removing the loudspeakers.

  1. Unscrew the fastening screws -1-  .
  2. Pull the tweeter -2-  out slightly -arrow A-  , and unplug the electric plug connection -3- -arrow B-  .
    3. Fig 1: Removing Tweeter (Premium)
    G09998982
