Installing The Tweeter (Premium), Left And Right

  1. Plug in the electric plug connection -3-  on the tweeter -2- -arrow A-  .
  2. Position the tweeter -2-  on the switch panel -arrow B-  and secure with the fastening screws -1-  . → Tightening torque: 2.5 Nm
    3. Fig 1: Installing Tweeter (Premium)
    G09998985
