Preparing Bonding Surfaces
Information
- The table below shows how to use cleaners, primers and activators when preparing the bonding surface.
| Preparing the body glass for installation | ||
|---|---|---|
| Old glass | New glass | |
| with preliminary coat (durable primer) | ||
| Cut back adhesive bead ↓ |
-cleaner- ↓ |
|
| Clean rim (ceramic layer with durable primer) ↓ |
||
| -activator- ↓ |
-primer- ↓ |
|
| Activate adhesive bead (only necessary after idle times > 24 h) ↓ |
Apply primer from the adhesive kit over the durable primer on the spare part ↓ |
|
| Applying adhesive | ||
| Install glass | ||
| Preparing the window flange for installation | ||
|---|---|---|
| Old flange (old paintwork) | New flange (new paintwork) | |
| Cut back adhesive bead ↓ |
-cleaner- ↓ |
|
| Clean flange surface ↓ |
||
| -activator- ↓ | -primer- ↓ |
|
| Activate adhesive bead (only necessary after idle times > 24 h) ↓ |
Prime flange surface ↓ |
|
| Apply adhesive | ||
| Install glass | ||
