Subsequent Work

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.

Fit spark plugs.
→ 287020 REMOVING AND INSTALLING SPARK PLUGS - section on "Installing".

Fig 1: Fitting Spark Plug
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
Install bar ignition module.
→ WM 282019 REMOVING AND INSTALLING IGNITION COIL .

→ Tightening torque: 10 Nm (7.5 ft. lb.)
Install upper part of heat shield.
→ 261219 REMOVING AND INSTALLING HEAT SHIELD
1. 3.1. Insert heat shield and fit and tighten two external Torx screws (E10, M6 x 12).
  → Tightening torque: 10 Nm (7.5 ft. lb.)
Install rear silencer.
→ 263319 REMOVING AND INSTALLING REAR SILENCER .
Mount rear wheels.
Socket-wrench insert P300 should be used to avoid damaging the rims.

→ 44051900 REMOVING AND INSTALLING WHEEL .
