Removing Rear Bumper

  1. Only For Vehicles With Exhaust Flaps:

    Unclip hose for exhaust flaps on the heat shield.

  2. Remove rear bumper -2-  .
    1. 2.1. Unscrew and remove fastening screws -1-  on the rear bumper -2-  .
    2. 2.2. Remove rear bumper -2-  with the heat protection panels fitted on it by pulling it to the rear.
    Fig 1: Identifying Rear Bumper Fastening Screws
    G10026996Courtesy of PORSCHE CARS NORTH AMERICA, INC.
