Removing Seal For Spur-Gear Cover

WARNING: This page is about a different variant/trim than selected.
  1. Unscrew fastening screws between transmission and mount for exhaust system and remove mount for exhaust system.
    Fig 1: Locating Exhaust System Fastening Screws
    G09587131Courtesy of PORSCHE CARS NORTH AMERICA, INC.

    Information

    The spur gears are prevented from falling out. Remove spur-gear cover to prevent wheels from falling out. Wheels that fall out must not be reinstalled. If this happens, the transmission must be replaced.

  2. Unscrew fastening screws for spur-gear cover and remove spur-gear cover.
  3. Prevent spur gearing from falling out.
