Installing Antenna Amplifier
- Position the antenna amplifier on the A-pillar and screw down the fastening screws -6- .
- Plug in the connectors for the antenna control unit -3, 4- on the left-hand side and -3, 4, 5- on the right-hand side.
- Plug in the antenna connectors for the windscreen -1- and -2- .
