Group 27: Generator
WARNING: This page is about a different variant/trim than selected.
TIGHTENING TORQUE SPECIFICATIONS - GENERATOR
| Location |
Description |
Type |
Basic value |
Tolerance |
| Fastening screw securing generator to engine, M8 |
|
Tightening torque |
23 (17 ftlb.) Nm |
|
 Courtesy of PORSCHE CARS NORTH AMERICA, INC.
|
Tightening fastening screws on the generator
