Installing Hood Compartment Lid: Notes

Position hood compartment lid on the hinges and screw down slightly with the fastening nuts -1- (-arrow-) . Adjust the hood compartment lid to the contours of the side panel and rear lid and screw down the fastening nuts. → WM 5X00IN DIAGRAM - BODY GAP DIMENSIONS (ALL MODELS) → Tightening torque: 9.7 Nm (7.5 ftlb.)

Fig 1: Installing Hood Compartment Lid
Courtesy of PORSCHE CARS NORTH AMERICA, INC.
