Removing rear speed sensor

  1. Raise the vehicle → 400000 LIFTING THE VEHICLE .
  2. Open combination plug connection -1-  and pull out connector for the speed sensor.

    Loosen fastening screw -2-  and remove the speed sensor.

    Fig 1: Identifying Plug Connection And Connector For Rear Speed Sensor
    G09825971Courtesy of PORSCHE CARS NORTH AMERICA, INC.
