Access For Opening And Closing The Hydraulic Valve (Emergency Operation)

To open, insert the Allen key -1-  through the bore on the roll-over bar module -3-  into the hydraulic valve -2-  and turn approx. 1 turn to the left -arrow-  .

Fig 1: Opening Hydraulic Valve

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

To close, insert the Allen key -1-  through the bore of the roll-over bar module -3-  into the hydraulic valve -2-  and turn to the right.
