Top Of Lower Side Member And Floor

Fig 1: Identifying Top Of Lower Side Member And Floor Plugs And Grommet Hole
G09831641Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  1. Rubber grommet hole Ø 20 mm
  2. Rubber grommet hole Ø 30 mm
  3. Cap hole Ø 30 mm
  4. Plug hole Ø 10 mm
  5. Cap hole Ø 20 mm
