Top Of Front Of Vehicle

Illustrated on the body of an all-wheel drive vehicle

G09822407Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  1. Rubber grommet hole Ø 20 mm
  2. Rubber grommet hole Ø 30 mm
  3. Plug hole Ø 35 mm
