Preparing Bonding Surfaces
Information
- The table below shows how to use cleaners, primers and activators when preparing the bonding surface.
| Preparing the body glass for installation | ||
| Old glass | New glass | |
| with preliminary coat (durable primer) | ||
| Cut back adhesive bead ? |
-cleaning agents- ↓ |
|
| Clean rim (ceramic layer with durable primer) ? |
||
| -activator- ↓ |
-primer- ↓ |
|
| Activate adhesive bead (only necessary if vehicle is idle for periods > 24 hours) ? |
Apply primer from the adhesive kit over the durable primer on the spare part ? |
|
| Apply adhesive | ||
| Install glass | ||
| Preparing the window flange for installation | ||
| Old flange (old paintwork) | New flange (new paintwork) | |
| Cut back adhesive bead ? |
-cleaning agents- ↓ |
|
| Clean flange surface ? |
||
| -activator- ↓ |
-primer- ↓ |
|
| Activate adhesive bead (only necessary if vehicle is idle for periods > 24 hours) ? |
Prime flange surface ? |
|
| Apply adhesive | ||
| Install glass | ||
