Locking plug connection for radio antenna

Installation Location:

Fig 1: Installation location of cowl panel cover

Courtesy of PORSCHE OF NORTH AMERICA, INC.

Fig 2: Disconnecting plug connection for radio antenna

Courtesy of PORSCHE OF NORTH AMERICA, INC.

NOTE: Only for vehicles with radio antenna.

1. Connect the antenna line and clip on the fuse.

2. Slide antenna onto its support and screw it down with the fastening screws -1- . See Fig 2.
