Removing and Installing Sun Visor



682319 Removing And Installing Sun Visor

Removing sun visor


Installation Position Of Sun Visor:






1. Unclip cover -1- with a screwdriver and unscrew the fastening screw -2-.
2. Pull off the sun visor -3- from the mounting saddle towards the centre of the car.


Removing Sun Visor:






Installing sun visor


Installation Position Of Sun Visor:






1. Insert sun visor -3- into the mounting saddle.
2. Position sun visor -3- and screw down using the fastening screw -2-.
3. Press in cover -1- until it engages.


Installing Sun Visor:
