Component overview

Fig 1: Component overview of oil pressure control valve

Courtesy of PORSCHE OF NORTH AMERICA, INC.

-1-  - Drive shaft for oil pump drive; component is symmetrical, thus it is not possible to install incorrectly. See Fig 1.

-2-  - Oil pump. See Fig 1.

-3-  - → Tightening torque: 17 ftlb.  See Fig 1.

-4-  - Gear wheels; tooth flank play: 0.20 mm; axial flank play: 0.10 mm. See Fig 1.

-5-  - → Opening pressure: 5.5 bar +/-0.2 bar  ; clean intake strainer. See Fig 1.

-6-  - → Tightening torque: 6 ftlb.  ; with screw locking agent medium-tight. See Fig 1.

-7-  - Oil pressure pipe; insert with sealant. See Fig 1.

-8-  - → Tightening torque: 6 ftlb.  See Fig 1.

-9-  - Sealing ring; replace if damaged. See Fig 1.
