Impermissible combination

Front-axle cross member with one fastening bore -F1-  and body with two fastening points -K2-  . See Fig 1 .

Fig 1: Identifying Front-Axle Cross Member (Impermissible Combination)
G03093748Courtesy of PORSCHE OF NORTH AMERICA, INC.


The combination - front-axle cross member with two fastening bores and (F2) and body with one fastening point (K1) - is not possible!
