Standard Boost Spring
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Porsche Boxster, 2003 Porsche Boxster, 2002 Porsche Boxster, 2001 Porsche Boxster, and 2000 Porsche Boxster. However, it is still accessible from the selected car via links, so may be relevant.
Push rod open on one side. Component not coated.
Grease pin for boost spring (arrow) with mating bearing on the boost spring push rod, the boost spring bearing (arrows) and the bearing pins on the boost spring with Optimol, Optitemp LG 2, part No. 000.043.203.37. First remove old grease with solvent naphtha.
The boost spring and the boost spring housing are greased with a special grease on the inside. This grease is not available as a spare part. Replace the entire boost spring (with boost spring housing) if necessary.
