BOXSTER As Of Mod. '98

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Porsche Boxster, 2003 Porsche Boxster, 2002 Porsche Boxster, 2001 Porsche Boxster, and 2000 Porsche Boxster. However, it is still accessible from the selected car via links, so may be relevant.

Silver bracket (986.423.571.00) and boost spring with white marking (986.423.081.08 or 986.423.081.11 / see boost spring allocation) must be used only in this combination and installed only in the Boxster.

NOTE:
  • The gold-colored bracket (996.423.571.00) and boost spring with purple marking (996.423.081.09 or 996.423.081.11) are assigned to the 911 Carrera (996) and must not be installed in the Boxster.
Fig 1: Identifying Gold-Colored Bracket And Boost Spring With Purple Marking
G03102604Courtesy of PORSCHE OF NORTH AMERICA, INC.
