Special Notes

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Porsche Boxster, 2003 Porsche Boxster, 2002 Porsche Boxster, 2001 Porsche Boxster, and 2000 Porsche Boxster. However, it is still accessible from the selected car via links, so may be relevant.

Check the fuel hose for correct routing. The fuel hose is routed behind the engine wiring harness.

Fig 1: Locating Fuel Hose
Courtesy of PORSCHE OF NORTH AMERICA, INC.
When installing the rear-axle parts, it is essential to observe the correct sequence. The sheetmetal brace should be installed first, then the diagonal brace and finally the rear-axle support.
The V-brace must be fitted before the exhaust system is installed.
Finally, perform a suspension alignment.
Read out fault memory.
