Measurement Of Closed-Circuit Current: Tools

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Porsche Boxster, 2003 Porsche Boxster, 2002 Porsche Boxster, 2001 Porsche Boxster, and 2000 Porsche Boxster. However, it is still accessible from the selected car via links, so may be relevant.

Closed-circuit current should be measured using an analog ammeter or a digital multimeter with a long integration time (to filter out voltage peaks).

Fig 1: Identifying Analog Ammeter (Special Tool)

Courtesy of PORSCHE OF NORTH AMERICA, INC.
