Installing cup holder

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Porsche Boxster, 2003 Porsche Boxster, 2002 Porsche Boxster, 2001 Porsche Boxster, and 2000 Porsche Boxster. However, it is still accessible from the selected car via links, so may be relevant.
  1. Installing cup holder

    Push cup holder -2-  into the shaft of the retaining bracket -3-  . Make sure that the metal clip -1-  engages.

    Refer to DISASSEMBLING AND ASSEMBLING THE INSTRUMENT PANEL .

Fig 1: Installing Cup Holder
G03155340Courtesy of PORSCHE OF NORTH AMERICA, INC.
