Tightening torques
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Porsche Boxster, 2003 Porsche Boxster, 2002 Porsche Boxster, 2001 Porsche Boxster, and 2000 Porsche Boxster. However, it is still accessible from the selected car via links, so may be relevant.
TIGHTENING SPECIFICATIONS - REAR BUMPER
| Location | See | Thread | Tightening torque | |
|---|---|---|---|---|
| Fastening screws of holder on body | -3- in Figure | M6 | 10Nm | (7.5 ftlb.) |
| Fastening screws of rear supports on rear bumper | -7- in Figure | M6 | 10Nm | (7.5 ftlb.) |
| Fastening screws of impact pipe or impact absorber on body | -10,10A- in Figure | M8 | 23Nm | (17ftlb.) |
| Fastening screws of bumper on impact pipe or impact absorber | -11,11A- in Figure | M10 | 85Nm | (63 ftlb.) |
