Four wheel drive vehicles

Fig 1: Identifying Booster Pump For PSM In Front Of Brake Booster
G03105819Courtesy of PORSCHE OF NORTH AMERICA, INC.

The booster pump -A-  is located in front of the brake booster -C-  in the 911 Carrera 4 and 911 Carrera 4S.
