Component Location

FUSES & RELAY BLOCK LOCATIONS

Component Location
Current Distributor (1)
Fuses Support Block Behind Cover In Driver-Side Footwell Kick Panel
Relay Support 1 Next To Fuses Support Block
Relay Support 2 Back Wall Of Engine Compartment On Left Side
(1) See Fig 1.
Fig 1: Identifying Current Distributor Location
G00186977Courtesy of PORSCHE OF NORTH AMERICA, INC.
