Installing the car radio

  1. Remove the heating/air-conditioning control. Rep. Gr. 870219; Removing and installing the heating/air-conditioning control.
  2. Engage the electrical plug connections on the car radio.
  3. Pull the special tool out of the car radio by pressing gently on the retaining spring -arrow-.
    Fig 1: Removing Heating/Air-Conditioning Control
    G03091615Courtesy of PORSCHE OF NORTH AMERICA, INC.
  4. Carefully push the car radio into place.
  5. Through the opening on the heating/air-conditioning control, it is possible to check the position of leads in the support frame better and to prevent leads from becoming trapped.
  6. Install the heating/air-conditioning control.
